MAX9959

25V Span, 800mA Device Power Supply (DPS)

Show More showmore-icon

Fully Integrated 25V Span, 800mA Device Power Supply for Industrial Test and Instrumentation Applications

Info: : PRODUCTION tooltip
Info: : PRODUCTION tooltip
Part Details
Part Models 1
1ku List Price Starting From $28.23
Features
  • 25V Span Output Voltage
  • Programmable Current and Voltage Compliance
  • Programmable Current Ranges
    • ±200µA
    • ±2mA
    • ±20mA
    • ±800mA
  • Load Regulation of 1mV at 800mA
  • External Buffer Support for Higher Currents
  • Parallel Multiple Devices for Higher Currents
  • Programmable Gain Allows a Wide Range of DACs
  • Device-Under-Test (DUT) Ground Sense
  • Programmable Compensation for Wide Range of Loads
  • Integrated Go/No-Go Comparators
  • IDDQ Test Mode
  • Range-Change Glitch Control
  • Compact (14mm x 14mm) Package
  • 3-Wire Compatible Serial Interface
  • Thermal Warning Flag and Thermal Shutdown
Additional Details
show more Icon

The MAX9959 provides all the key features of a device power supply (DPS) common to automatic test equipment (ATE) and other instrumentation. Its small size, high level of integration, and superb flexibility make the MAX9959 ideal and economical for multisite systems requiring many device power supplies.

The MAX9959 has multiple input control voltages that allow independent setting of both the output voltage, and the maximum and minimum (smallest positive or most negative) voltage or current. The MAX9959 is a voltage source when the load current is between the two programmed limits, and transitions gracefully into a precision current source/sink if a programmed current limit is reached. The output features two independently adjustable voltage clamps that limit both the negative and positive output voltage values between levels externally provided.

The MAX9959 can source voltages spanning 25V and can source currents as high as ±800mA. The DPS can support an external buffer for sourcing and sinking higher currents. Multiple MAX9959s can be configured in parallel to load-share, allowing higher output currents with greater flexibility.

The MAX9959 features operation over a wide range of loading conditions. Programmability allows optimizing of settling time, over-/undershoot, and stability. Built-in, configurable, range-change glitch-control circuits minimize output glitches during range transitions.

The MAX9959 offers load regulation of 1mV at 800mA load.

The MAX9959D features an internal 300kΩ sense resistor (RFS), between RCOMF and SENSE. The MAX9959F does not include this sense resistor. Both devices are available in the 100-pin TQFP package with an exposed pad on the top for heat removal.

Applications

  • Industrial Systems
  • Memory Testers
  • Structural Testers
  • System-on-a-Chip Testers
  • VLSI Testers
Part Models 1
1ku List Price Starting From $28.23

close icon
Documentation

Documentation

Part Model Pin/Package Drawing Documentation CAD Symbols, Footprints, and 3D Models
MAX9959DCCQ+D
  • HTML
  • HTML
Software & Part Ecosystem

Software & Part Ecosystem

Evaluation Kit

Evaluation Kits 1

MAX9959EVKIT

Evaluation Kit for the MAX9959

zoom

MAX9959EVKIT

Evaluation Kit for the MAX9959

Evaluation Kit for the MAX9959

Features and Benefits

  • Easy Evaluation of the MAX9959
  • On-Board Voltage Reference (MAX6126)
  • On-Board DACs for Level Setting
  • On-Board ADC for Measurements
  • On-Board Regulators Generate All the Required Voltages from ±12V
  • USB Interface
  • Headers for External SPI and DACs
  • Proven PCB Layout
  • Includes Heatsink and Fan
  • Fully Assembled and Tested

Product Detail

The MAX9959 evaluation kit (EV kit) is a fully assembled and tested printed circuit board (PCB) design that evaluates the functionality of device power supply (DPS) IC MAX9959, which has 25V span output voltage and programmable current ranges up to 800mA.

The MAX9959 EV kit contains a microcontroller (MCU) that translates between the SPI interface and USB to allow the user to configure internal registers and modes with graphical user interface (GUI) software running on a PC. The EV kit includes Windows® 10-compatible software that provides a simple GUI for configuration of all the MAX9959 registers through SPI. The EV kit is fully assembled and tested at the factory.

This document provides a list of equipment required to evaluate the device, a straightforward test procedure to verify functionality, a description of the EV kit circuit, component list, circuit schematic, and artwork for each layer of the PCB. The MAX9959 EV kit PCB comes with a MAX9959DCCQ+ installed.

Applications

  • Industrial Systems
  • Memory Testers
  • Structural Testers
  • System-on-a-Chip Testers
  • VLSI Testers
