MAX22507E

PRODUCTION

50Mbps Full-Duplex RS-485/RS-422 Transceivers with High EFT Immunity

50Mbps RS-485/RS-422 Transceivers with High EFT Immunity

Data Sheet (Rev. 1) Product Selection Table

Part Models: 2
1ku List Price: Starting From $2.00

Viewing:

Overview

High-Speed Operation Over Long Distances
- Up to 50Mbps Data Rate
- High Receiver Sensitivity
- Wide Receiver Bandwidth
- Symmetrical Receiver Thresholds
Integrated Protection Increases Robustness
- -15V to +15V Common Mode Range
- ±15kV ESD Protection (Human Body Model)
- ±7kV IEC 61000-4-2 Air-Gap ESD Protection
- ±6kV IEC 61000-4-2 Contact Discharge ESD Protection
- Withstands Over ±4kV EFT
- Driver Outputs are Short-Circuit Protected
Flexibility for Many Different Applications
- 3V to 5.5V Supply Range
- Low 5µA (max) Shutdown Current (MAX22507E)
- Allows up to 200 Transceivers on the Bus
- Available in a 10-pin µMAX Package (MAX22507E) and 8-pin SOIC Package (MAX22508E)
- -40°C to +125°C Operating Temperature Range

The MAX22507E/MAX22508E ESD-protected RS-485/RS-422 full duplex transceivers are optimized for high-speed communication up to 50Mbps. These transceivers feature integrated hot-swap protection and a fail-safe receiver, ensuring a logic-high on the receiver output when input signals are shorted or open for longer than 10µs (typ). Additionally, a large receiver hysteresis improves noise rejection and signal integrity.

The MAX22507E/MAX22508E are designed to operate in harsh industrial environments and are optimized for robust communication in environments with high levels of electromagnetic interference (EMI).

The MAX22507E is available in a 10-pin µMAX package and the MAX22508E is available in an 8-pin SOIC package. µMAX is the Maxim-trademarked equivalent to the industry-standard MSOP package. Both transceivers operate over the -40°C to +125°C temperature range.

Applications

Motion Control
Encoder Interfaces
Field Bus Networks
Industrial Control Systems
Backplane Busses

Part Models: 2
1ku List Price: Starting From $2.00

Documentation

Data Sheet 1

MAX22507E-MAX22508E: 50Mbps Full-Duplex RS-485/RS-422 Transceivers with High EFT Immunity Data Sheet (Rev.1) 09/20/2021

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
MAX22507EAUB+	10-MINI_SO-N/A	Material Declaration Reliablity Data Package Resources	Ultra Librarian SamacSys
MAX22507EAUB+T	10-MINI_SO-N/A	Material Declaration Reliablity Data Package Resources	Ultra Librarian SamacSys

This is the most up-to-date revision of the Data Sheet.

Tools & Simulations

IBIS Model 1

MAX22507E IBIS Model

Evaluation Kits

Evaluation Kit for the MAX22507E/MAX22508E

Buy Now View Details

Features and Benefits

Operates from a Single 3V to 5V Supply
Terminal Block Connectors for Easy RS-485/RS-422 Evaluation
Fully Assembled and Tested

Product Details

The MAX22507E evaluation kit (EV kit) is a fully assembled and tested PCB that demonstrates the functionality of the MAX22507E and the MAX22508E full-duplex high speed RS-485/RS-422 transceiver. The EV kit includes on-board termination for easy point-to-point evaluation. The EV kit is assembled using MAX22507E in a 10-pin TDFN package, but also provides equivalent functional evaluation for the MAX22508E, which is offered in a 8-pin SOIC package.
