MAX22503E

100Mbps Full-Duplex 3V/5V RS-485/RS-422 Transceiver with High EFT Immunity

Show More showmore-icon

100Mbps Full-Duplex 3V/5V RS-485/RS-422 Transceiver with High EFT Immunity in SOIC 14 package

Info: : PRODUCTION tooltip
Info: : PRODUCTION tooltip
Viewing: Part Details
arrow-icon
Part Details

Not the part you were looking for?

viewall Go to Product Selection Table
file View Data Sheet (Rev.0)
Documentation View All Documentation
IBIS Model MAX22503E IBIS Model Download 1.03MB
Part Models 2
1ku List Price Starting From $5.17
Features
  • High-Speed Operation
    • Up to 100Mbps Data Rate
    • High Receiver Sensitivity
    • Wide Receiver Bandwidth
    • Symmetrical Receiver Thresholds
  • Integrated Protection Increases Robustness
    • -15V to +15V Common Mode Range
    • ±15kV ESD Protection (Human Body Model)
    • ±7kV IEC61000-4-2 Air-Gap ESD Protection
    • ±6kV IEC61000-4-2 Contact Discharge ESD Protection
    • Short-Circuit Protected Driver Outputs
  • Flexibility for Many Different Applications
    • 3V to 5.5V Supply Range
    • Low 5μA (max) Shutdown Current
    • Available in 14-Pin SOIC Package
    • -40°C to +125°C Operating Temperature Range
Additional Details
show more Icon

The MAX22503E full-duplex, ESD-protected, RS-485/RS-422 transceiver for high-speed communication operates up to 100Mbps. This transceiver features larger receiver hysteresis for high noise rejection and improved signal integrity. Integrated hot-swap protection and a fail-safe receiver ensure a logic-high on the receiver output when input signals are shorted or open for longer than 10μs (typ).

The MAX22503E is available in 14-pin SOIC package and operates over the -40°C to +125°C ambient temperature range.

Applications

  • Motion Control
  • Encoder Interfaces
  • Field Bus Networks
  • Industrial Control Systems
  • Backplane Busses
Show More Arrow image
file View Data Sheet (Rev.0)
Documentation View All Documentation
IBIS Model MAX22503E IBIS Model Download 1.03MB
Part Models 2
1ku List Price Starting From $5.17
