MAX17841B
PRODUCTIONAutomotive SPI Communication Interface (ASCI)
Enables Robust Daisy-Chain EMC/EMI Performance and Cost Effective Isolation Solution
- Part Models
- 4
- 1ku List Price
- Starting From $4.69
Overview
- Supports Maxim’s Battery Management UART Protocol
- SPI Interface Up to 4MHz
- UART Baud Rate Programmable Up to 2Mbps
- 3.3V or 5V Operation
- Ultra-Low Quiescent Current
- Transmit and Receive Buffers with Programmable Interrupts Allow for Queuing of UART Messages
- Manchester Encoder and Decoder Reduces Host Controller Burden
- Operating Temperature Range from -40°C to +105°C (AEC-Q100 Type 2)
- Supports ASIL Requirements
The MAX17841B ASCI combines an SPI port with a universal asynchronous receiver transmitter (UART) specially designed to interface with Maxim battery management devices.
The UART can be configured to automatically perform Manchester encoding/decoding, message framing, parity, wake-up, and keep-alive signaling as required for Maxim’s battery management UART protocol.
The UART has programmable baud rates of 0.5Mbps, 1Mbps, or 2Mbps and supports either single-ended or differential signaling. For host efficiency, the UART contains a 28-byte transmit buffer and a 62-byte receive buffer with host-configurable interrupt events.
Applications
- Battery Management Systems (BMS)
- Electric and Hybrid Vehicles (EV/HEV)
- Energy Storage Systems (ESS)
Documentation
Data Sheet 1
Product Highlight 1
Video 1
Product Highlight 1
ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.
| Part Model | Pin/Package Drawing | Documentation | CAD Symbols, Footprints, and 3D Models |
|---|---|---|---|
| MAX17841BGUE+ | Thin Shrink Small-Outline Package | ||
| MAX17841BGUE+T | Thin Shrink Small-Outline Package | ||
| MAX17841BGUE/V+ | Thin Shrink Small-Outline Package | ||
| MAX17841BGUE/V+T | Thin Shrink Small-Outline Package |
This is the most up-to-date revision of the Data Sheet.
Hardware Ecosystem
| Parts | Product Life Cycle | Description |
|---|---|---|
| Battery Monitors & Fuel Gauges 1 | ||
| MAX17843 | PRODUCTION | 12-Channel, High-Voltage Smart Sensor Data-Acquisition Interface |
Tools & Simulations
Software Development 1
Evaluation Kits
Evaluation Kit for the MAX17841B
