Overview

Features and Benefits

  • Four video input ports capable of accepting any of the following formats: single-ended CVBS, S-video (Y/C), and component (YPbPr)
  • Digital (ITU-R BT.656) and YPbPr outputs

Product Details

The EVAL-ADV7280AEBZ evaluation kit is the platform provided by Analog Devices, Inc., to evaluate the ADV7280A video decoder. The EVAL-ADV7280AEBZ evaluation kit contains an EVAL-ADV7280AEBZ evaluation board and all of its necessary peripherals.

This user guide provides a detailed overview of the EVAL-ADV7280AEBZ evaluation board hardware and the software required to use it.

The ADV7280A data sheet and the ADV7280A/ADV7281A/ADV7282A Device Manual should be consulted in conjunction with this user guide when using the EVAL-ADV7280AEBZ evaluation board.

EngineerZone can be accessed to find additional information about the ADV7280A.

Markets and Technologies

Applicable Parts

Package Contents

  • EVAL-ADV7280AEBZ evaluation board
  • 7.5 V power supply block
  • USB cable

Documentation & Resources

  • View All (3)
  • User Guides (2)
  • Evaluation Design Files (1)
    • Document Type

    Software

    Design Tools

    ZIP
    27.76 K
    ADV7280A Evaluation Board Script Files
    ADV7280A Evaluation Board Script Files and XMLs
