EVAL-HMC797APM5
HMC797APM5评估板
顶部
概览
优势和特点
- 2-layer Rogers 4350B evaluation board with heat spreader and wideband, surface-mount bias tee circuit
- End launch, 2.92 mm RF connectors
- Through calibration path
产品详情
本页提供评估HMC797APM5的评估板订购信息。
系统需求
- RF signal generator
- RF spectrum analyzer
- RF network analyzer
- 10 V, 0.7 A power supply
- −1.5 V, 100 mA power supply
文档
-
HMC797APM5E Gerber Files2017/9/26ZIP3 M
