EVAL-ADV7282A-M

ADV7282A-M Evaluation Board

Top
User Guides Rev. 0
2 View All

Overview

Features and Benefits

  • Six video input ports capable of accepting any of the following formats: single-ended CVBS, differential CVBS, S-Video (Y/C), and component (YPbPr)
  • MIPI CSI-2 Tx output

Product Details

The EVAL-ADV7282AMEBZ evaluation kit is the platform provided by Analog Devices, Inc., to evaluate the ADV7282A-M video decoder. The EVAL-ADV7282AMEBZ evaluation kit contains an EVAL-ADV7282AMEBZ evaluation board and all of its necessary peripherals.

This user guide provides a detailed overview of the EVAL-ADV7282AMEBZ evaluation board hardware and the software required to use it.

The ADV7282A-M data sheet and the ADV7280A/ADV7281A/ ADV7282A Device Manual should be consulted in conjunction with this user guide when using the EVAL-ADV7282AMEBZ evaluation board.

EngineerZone can be accessed to find additional information about the ADV7282A-M.

Markets and Technologies

Applicable Parts

Package Contents

  • EVAL-ADV7282AMEBZ evaluation board
  • 7.5 V power supply block
  • USB cable
