Demonstration circuit 2472A is a USB-powered resistorstring, voltage ladder with variable output. The DC2472A provides a simple battery stack simulator for connection directly to most of ADI's LTC68xx “battery stack monitor” demo boards.
Documentation & Resources
DC2472A - Schematics12/5/201744K
DC2472A - Demo Board Manual12/5/2017267K
DC2472A - Design Files12/5/2017ZIP1M
