下一代气象雷达
Analog Devices offers a full lineup of X-band signal chain components—from the RF front end to integrated data converters—to support modern phased-array weather radar solutions. We provide access to and expertise in a wide range of process technologies to help you maximize performance and minimize SWaP, including GaN PAs for power efficiency, X-band digitally tunable filters, and active antenna solutions using beamformers, phase shifters, and DSP-enabled digitizers.
价值和优势
- 提升气象监测安全性： X波段相控阵雷达可实现实时监测，对强对流天气进行早期预警。
- 优化尺寸、重量和功耗： 氮化镓(GaN)功率放大器、可调谐X波段滤波器及有源天线解决方案，实现尺寸、重量与功耗的最小化。
- 集成式信号链： 覆盖射频前端至数据转换器，为完整的雷达系统设计提供支持。
- 设计灵活性： 多元工艺技术，助力性能最大化。
Key Resources
Bulletins and Brochures
Phased Array
-
PDF
Phased Array ICs
638 K
互动式信号链
Trainings and Tutorials
文件和下载
数据手册
ADTR1107: 6 GHz to 18 GHz, Front-End IC Data Sheet
1.72 M
ADAR1000: 8 GHz to 16 GHz, 4-Channel, X Band and Ku Band Beamformer Data Sheet
1.7 M
解决方案设计及宣传手册
Beamforming Brochure - Providing High Speed Data Where You Need It and When You Need It
2.37 M
Phased Array Brochure
961.15 K
