MAX14919A
Industrial-Protected Quad-Channel Low-Side Switch
Industry's Most Robust, Fastest Low-Side Switch
Top
Overview
Features and Benefits
- 5V or 7V to 60V Supply Voltage
- 800mA Load Current per OUT
- Integrated 5V/30mA Linear Regulator
- Logic Supply Input from 1.62V(min) to 5.5V(max)
- 5V to 48V Load Voltage Range
- Up to 500kHz Switching Rates
- 2x Inrush Load Current Option for 10ms
- Reduces Power and Heat Dissipation
- 140mΩ (typ) On-Resistance per channel
- 1.7mA (typ) Supply Current
- Settable Load Current Limit
- Robust Design Features
- Internal inductive Energy Clamp at 55V(typ)
- Short-Circuit Protection
- Reverse Current Detection against Load-Supply Miswiring
- ±1kV/42Ω, 8μs/20µs Surge Protection
- ±8kV Contact and ±25kV Airgap ESD Protection
- -40°C to +125°C Operating Ambient Temperature
- Active-Low FAULT Indication for:
- Thermal Overload
- Reverse Load Current Detection
- Undervoltage Lockout on V5 Supply
- Compact 20-pin, 6.5mm x 6.4mm TSSOP Package
- Compact 20-pin, 4mm x 5mm TQFN Package
Product Details
The MAX14919/MAX14919A industrial-protected quad-channel lowside switch features 140mΩ (typ) on-resistance (RON) per channel with integrated ±1kV/42Ω surge protection for robust operation.
Resistor-settable accurate current limiting provides guaranteed operating currents in the range of 100mA to 800mA. Loads that draw large activation or inrush currents are supported using the 2x inrush load-current option. The outputs can be connected in parallel to achieve higher load currents. The four switches are pin-controlled to allow for simple and fast switching of up to 500kHz.
The MAX14919/MAX14919A features reverse current detection. The MAX14919 implements reverse-current protection by driving an external FET for non-capacitive loads. The MAX14919A has reverse current indication.
Inductive loads are turned off rapidly using the internal high-voltage clamps. The switches are short-circuit and overload protected.
The MAX14919/MAX14919A quad low-side switch is available in a 6.5mm x 6.4mm footprint, 20-TSSOP package and a 4mm x 5mm footprint 20-TQFN package specified over the -40°C to +125°C operating temperature range.
Applications
- Industrial Digital Outputs
- Relay and Solenoid Drivers
- PLC and DCS Systems
- Motor Control
