Features and Benefits

  • 20 MHz maximum external clock rate
  • Second-order modulator
  • 16 bits, no missing codes
  • ±2 LSB INL typical at 16 bits
  • 1 µV/°C typical offset drift
  • On-board digital isolator
  • On-board reference
  • ±250 mV analog input range
  • Low power operation: 17 mA typical at 5.5 V
  • −40°C to +125°C operating range
  • 16-lead SOIC package
  • Internal clock version: AD7400A
  • Safety and regulatory approvals
    • UL recognition
      • 5000 V rms for 1 minute per UL 1577
    • CSA Component Acceptance Notice #5A
    • VDE Certificate of Conformity
      • DIN V VDE V 0884-10 (VDE V 0884-10):2006-12
      • VIORM = 891 V peak
  • Qualified for Automotive Applications

Product Details

The AD7401A is a second-order, sigma-delta (Σ-Δ) modulator that converts an analog input signal into a high speed, 1-bit data stream with on-chip digital isolation based on the Analog Devices, Inc., iCoupler® technology. The AD7401A operates from a 5 V power supply and accepts a pseudo-differential input signal of ±250 mV (±320 mV full scale). The analog input is continuously sampled by the analog modulator, eliminating the need for external sample-and-hold circuitry. The input information is contained in the output stream as a density of ones with a data rate of up to 20 MHz. The original information can be reconstructed with an appropriate digital filter. The serial I/O can use a 5 V or a 3.3 V supply (VDD2).

The serial interface is digitally isolated. High speed CMOS, combined with Analog Devices, Inc., iCoupler® technology, means the on-chip isolation provides outstanding performance characteristics, superior to alternatives such as optocoupler devices. The device contains an on-chip reference. The AD7401A is offered in a 16-lead SOIC and has an operating temperature range of −40°C to +125°C.


  • AC motor controls
  • Shunt current monitoring
  • Data acquisition systems
  • Analog-to-digital and opto-isolator replacements

Product Lifecycle icon-recommended Production

At least one model within this product family is in production and available for purchase. The product is appropriate for new designs but newer alternatives may exist.
