製品概要

機能と利点

  • HART Compatible Secondary Master with the Ability to Connect to Existing 4-20mA Current Loop and Communicate with HART Enabled Devices
  • USB 2.0 Micro B to Serial UART
  • Two On-Board, High-Precision Voltage References
  • All GPIOs Signals Accessed Through 0.1in Headers
  • Access to 4 Analog Inputs Through SMA Connectors Configured as Differential
  • Access to 8 Analog Inputs Through 0.1in Headers Configured as Single-Ended
  • DAC Output Accessed Through SMA Connector or Test Point
  • 10-Pin SWD and Connector
  • Board Power Provided by USB Port
  • On-Board 1.0V, 1.8V, and 3.3V LDO Regulators
  • Individual Power Measurement on all IC Rails Through Jumpers
  • Two General-Purpose LEDs and Two General- Purpose Pushbutton Switches

製品概要

アプリケーション

  • 4~20mA産業用センサーおよびトランスミッタ
  • 産業用圧力、温度、流量、およびレベルセンサー/トランスミッタ
  • 医療用圧力、温度、および流量センサー
