The HMC987LP5E Evaluation board can be controlled via parallel port or SPI (Serial Port Interface). Parallel port control is implemented by simple jumper settings on the evaluation board. Serial Port interface offers more flexibility. This HMC987LP5E Evaluation Kit also includes the PC compatible software with Graphical User Interface (GUI), and software drivers necessary for Serial Port Interface, allowing the user to read from and write to all device registers, set gain levels and save & recall device configurations
The page contains ordering information for evaluating the HMC987LP5E.
The design files link includes the BOM, schematics, and Gerber files for the evaluation board.
関連資料
-
HMC987 Design Files2020/12/08ZIP12 M
-
HMC987LP5E Eval. PCB Schematic2015/04/22PDF560 K
-
User Manual - Hardware & Software Installation - HMC987LP5E Evaluation Kit2015/04/22PDF1 M
