µModule 降压型稳压器
Analog Devices 的降压型 µModule® 稳压器是完整的系统级封装 (SiP) 电源管理解决方案，具有集成化 DC-DC 控制器、功率晶体管、输入和输出电容器、补偿组件和电感器，采用紧凑的表面贴装型 BGA 或 LGA 封装。某些产品具有可调电流限制、低 EMI EN 55022 Class B 标准相符性、以及电流供应和吸收能力等额外特点。µModule 降压型稳压器能够有效地满足那些需要高效率和可靠的电源管理解决方案、同时面临着时间和空间限制条件的工程师之需求。
产品选型表
11436
cn
Quick Power Search
最新优势资源
技术文章
- Easy High Density Power: 48A Surface Mount DC/DC Power Supply Uses Four Parallel 12A μModule Regulators
- Dual Output µModule DC/DC Regulator Produces High Efficiency 4A Outputs from a 4.5V to 26.5V Input
- Easy Multivoltage Layout with Complete Dual and Triple Output Point-of-Load μModule Regulators in 15mm × 15mm Packages
- Complete 20V, 20A High Performance µModule DC/DC Regulator in 15mm × 15mm × 4.32mm Package
- μModule Regulator Powers and Protects Low Voltage μProcessors, ASICs and FPGAs from Intermediate Bus Voltage Surges
- µModule Regulator Charges Supercapacitor Backup Supply, Supporting LDO Outputs When the Input Supply Fails
- Real Power Density: 26A μModule Regulator Keeps Cool in Tight Spaces
- Ultralow Noise 15mm × 15mm × 2.8mm µModule Step-Down Regulators Meet the Class B of CISPR 22 and Yield High Efficiency at up to 36VIN
- Dual 8A DC/DC µModule Regulator Is Easily Paralleled for 16A
- µModule Regulator Combines a Switcher with Five 1.1A LDOs: Use Them for Multiple Low Noise Rails, or Parallel Them to Spread Heat and Share Current to 5A
- EMI Certified Step-Down Converter in 15mm × 9mm μModule Package Produces 1A, 0.8VOUT – 10VOUT from 3.6VIN – 36VIN
- Eliminate EMI Worries with 2A, 15mm × 9mm × 2.82mm µModule Step-Down Regulator
- μModule Regulators Shrink Power Supply Size and Design Effort
- Ultrathin Triple Output µModule Regulator for DDR, QDR and QDR-IV SRAM Fits 0.5cm2 Area and Backside of PCB
解决方案通报和手册
µModule 降压型稳压器
| SortOrder | Part# | Number of Outputs | Vin (min) (V) | Vin (max) (V) | Output Current (typ) (A) | Output Current 2 (typ) (A) | Vout Min (typ) (V) | Vout Max (typ) (V) | Price (1000+) ($ US) |
|---|---|---|---|---|---|---|---|---|---|
| 1 | LTM4657 | 1 | 3.1 | 20 | 8 | - | 500m | 5.5 | $6.48 (LTM4657EY#PBF) |
| 2 | LTM8024 (single output) | 1 | 3 | 40 | 7 | - | 800m | 8 | $11.65 (LTM8024EY#PBF) |
| 3 | LTM8024 (dual output) | 2 | 3 | 40 | 3.5 | 3.5 | 800m | 8 | $11.65 (LTM8024EY#PBF) |
| 4 | LTM4691 | 2 | 2.25 | 3.6 | 2 | 2 | 500m | 2.5 | $2.84 (LTM4691EV#PBF) |
| 5 | LTM4668A | 4 | 2.7 | 17 | 1.2 | 1.2 | 600m | 5.5 | $6.55 (LTM4668AEY#PBF) |
| 6 | LTM4668 | 4 | 2.7 | 17 | 1.2 | 1.2 | 600m | 1.8 | $6.55 (LTM4668EY#PBF) |
| 7 | LTM8078 (single output) | 1 | 3 | 40 | 2.8 | - | 800m | 10 | $6.53 (LTM8078EY#PBF) |
| 8 | LTM8078 (dual output) | 2 | 3 | 40 | 1.4 | 1.4 | 800m | 10 | $6.53 (LTM8078EY#PBF) |
| 9 | LTM4671 | 4 | 3.1 | 20 | 12 | 12 | 600m | 3.3 | $27.48 (LTM4671EY#PBF) |
| 10 | LTM4664 (single output) | 1 | 30 | 58 | 50 | - | 500m | 1.5 | $57.48 (LTM4664EY#PBF) |
| 11 | LTM4664 (dual output) | 2 | 30 | 58 | 25 | 25 | 500m | 1.5 | $57.48 (LTM4664EY#PBF) |
| 12 | LTM8074 | 1 | 3.2 | 40 | 1.2 | - | 800m | 12 | $3.83 (LTM8074EY#PBF) |
| 13 | LTM8071 | 1 | 3.6 | 60 | 5 | - | 970m | 15 | $14.53 (LTM8071EY#PBF) |
| 14 | LTM8002 | 1 | 3.4 | 40 | 2.5 | - | 970m | 18 | $9.12 (LTM8002IY#PBF) |
| 15 | LTM4700 (single output) | 1 | 4.5 | 16 | 100 | - | 500m | 1.8 | $97.26 (LTM4700EY#PBF) |
| 16 | LTM4700 (dual output) | 2 | 4.5 | 16 | 50 | 50 | 500m | 1.8 | $97.26 (LTM4700EY#PBF) |
| 17 | LTM4680 (single output) | 1 | 4.5 | 16 | 60 | - | 500m | 3.3 | $58.00 (LTM4680EY#PBF) |
| 18 | LTM4680 (dual output) | 2 | 4.5 | 16 | 30 | 30 | 500m | 3.3 | $58.00 (LTM4680EY#PBF) |
| 19 | LTM4686-1 (single output) | 1 | 2.375 | 17 | 20 | - | 500m | 3.6 | $23.23 (LTM4686EV-1#PBF) |
| 20 | LTM4686-1 (dual output) | 2 | 2.375 | 17 | 10 | 10 | 500m | 3.6 | $23.23 (LTM4686EV-1#PBF) |
| 21 | LTM4686 (single output) | 1 | 4.5 | 17 | 20 | - | 500m | 3.6 | $23.23 (LTM4686EV#PBF) |
| 22 | LTM4686 (dual output) | 2 | 4.5 | 17 | 10 | 10 | 500m | 3.6 | $23.23 (LTM4686EV#PBF) |
| 23 | LTM4678 (single output) | 1 | 4.5 | 16 | 50 | - | 500m | 3.3 | $47.48 (LTM4678EY#PBF) |
| 24 | LTM4678 (dual output) | 2 | 4.5 | 16 | 25 | 25 | 500m | 3.3 | $47.48 (LTM4678EY#PBF) |
| 25 | LTM4662 (single output) | 1 | 4.5 | 20 | 30 | - | 600m | 5.5 | $28.75 (LTM4662EY#PBF) |
| 26 | LTM4662 (dual output) | 2 | 4.5 | 20 | 15 | 15 | 600m | 5.5 | $28.75 (LTM4662EY#PBF) |
| 27 | LTM4653 | 1 | 3.1 | 58 | 4 | - | 500m | 54.52 | $12.55 (LTM4653EY#PBF) |
| 28 | LTM4646 (single output) | 1 | 4.5 | 20 | 20 | - | 600m | 5.5 | $18.85 (LTM4646EY#PBF) |
| 29 | LTM4646 (dual output) | 2 | 4.5 | 20 | 10 | 10 | 600m | 5.5 | $18.85 (LTM4646EY#PBF) |
| 30 | LTM4638 | 1 | 3.1 | 20 | 15 | - | 600m | 5.5 | $13.80 (LTM4638EY#PBF) |
| 31 | LTM4626 | 1 | 3.1 | 20 | 12 | - | 600m | 5.5 | $10.50 (LTM4626EY#PBF) |
| 32 | LTM8065 | 1 | 3.4 | 40 | 2.5 | - | 970m | 18 | $7.75 (LTM8065EY#PBF) |
| 33 | LTM8063 | 1 | 3.2 | 40 | 2 | - | 800m | 15 | $6.95 (LTM8063EY#PBF) |
| 34 | LTM4645 | 1 | 4.7 | 15 | 25 | - | 600m | 1.8 | $26.23 (LTM4645EY#PBF) |
| 35 | LTM4622A (single output) | 1 | 3.6 | 20 | 4 | - | 1.5 | 12 | $7.15 (LTM4622AEV#PBF) |
| 36 | LTM4622A (dual output) | 2 | 3.6 | 20 | 2 | 2 | 1.5 | 12 | $7.15 (LTM4622AEV#PBF) |
| 37 | LTM8073 | 1 | 3.4 | 60 | 3 | - | 800m | 15 | $10.58 (LTM8073EY#PBF) |
| 38 | LTM4650A-1 (dual output) | 2 | 4.5 | 16 | 25 | 25 | 600m | 5.5 | $48.00 (LTM4650AEY-1#PBF) |
| 39 | LTM4650A (dual output) | 2 | 4.5 | 16 | 25 | 25 | 600m | 5.5 | $48.00 (LTM4650AEY#PBF) |
| 40 | LTM4636-1 | 1 | 4.7 | 15 | 40 | - | 600m | 3.3 | $40.10 (LTM4636EY-1#PBF) |
| 41 | LTM4643 | 4 | 4 | 20 | 3 | 3 | 600m | 3.3 | $19.90 (LTM4643EV#PBF) |
| 42 | LTM8053 | 1 | 3.4 | 40 | 3.5 | - | 970m | 15 | $9.66 (LTM8053EY#PBF) |
| 43 | LTM8003 | 1 | 3.4 | 40 | 3.5 | - | 970m | 18 | $11.30 (LTM8003IY#PBF) |
| 44 | LTM4642 (single output) | 1 | 4.5 | 20 | 8 | - | 600m | 5.5 | $16.00 (LTM4642EY#PBF) |
| 45 | LTM4642 (dual output) | 2 | 4.5 | 20 | 4 | 4 | 600m | 5.5 | $16.00 (LTM4642EY#PBF) |
| 46 | LTM4631 (single output) | 1 | 4.5 | 15 | 20 | - | 600m | 1.8 | $24.88 (LTM4631EV#PBF) |
| 47 | LTM4631 (dual output) | 2 | 4.5 | 15 | 10 | 10 | 600m | 1.8 | $24.88 (LTM4631EV#PBF) |
| 48 | LTM8064 | 1 | 6 | 58 | 6 | - | 1.2 | 36 | $16.50 (LTM8064EY#PBF) |
| 49 | LTM4650-1 (single output) | 1 | 4.5 | 15 | 50 | - | 600m | 1.8 | $46.75 (LTM4650EY-1B#PBF) |
| 50 | LTM4650-1 (dual output) | 2 | 4.5 | 15 | 25 | 25 | 600m | 1.8 | $46.75 (LTM4650EY-1B#PBF) |
| 51 | LTM4632 | 3 | 3.1 | 15 | 3 | 3 | 600m | 2.5 | $7.35 (LTM4632EV#PBF) |
| 52 | LTM4650 (single output) | 1 | 4.5 | 15 | 50 | - | 600m | 1.8 | $46.75 (LTM4650EY#PBF) |
| 53 | LTM4650 (dual output) | 2 | 4.5 | 15 | 25 | 25 | 600m | 1.8 | $46.75 (LTM4650EY#PBF) |
| 54 | LTM4647 | 1 | 4.7 | 15 | 30 | - | 600m | 1.8 | $29.70 (LTM4647EY#PBF) |
| 55 | LTM4636 | 1 | 4.7 | 15 | 40 | - | 600m | 3.3 | $38.85 (LTM4636EY#PBF) |
| 56 | LTM4630A (single output) | 1 | 4.5 | 15 | 36 | - | 600m | 5.3 | $36.30 (LTM4630AEV#PBF) |
| 57 | LTM4630A (dual output) | 2 | 4.5 | 15 | 18 | 18 | 600m | 5.3 | $36.30 (LTM4630AEV#PBF) |
| 58 | LTM4630-1 (single output) | 1 | 4.5 | 15 | 36 | - | 600m | 1.8 | $36.05 (LTM4630EY-1B#PBF) |
| 59 | LTM4630-1 (dual output) | 2 | 4.5 | 15 | 18 | 18 | 600m | 1.8 | $36.05 (LTM4630EY-1B#PBF) |
| 60 | LTM4676A (single output) | 1 | 4.5 | 26.5 | 26 | - | 500m | 5.5 | $33.95 (LTM4676AEY#PBF) |
| 61 | LTM4676A (dual output) | 2 | 4.5 | 26.5 | 13 | 13 | 500m | 5.5 | $33.95 (LTM4676AEY#PBF) |
| 62 | LTM4675 (single output) | 1 | 4.5 | 17 | 18 | - | 500m | 5.5 | $24.00 (LTM4675EY#PBF) |
| 63 | LTM4675 (dual output) | 2 | 4.5 | 17 | 9 | 9 | 500m | 5.5 | $24.00 (LTM4675EY#PBF) |
| 64 | LTM4622 (single output) | 1 | 3.1 | 20 | 5 | - | 600m | 5.5 | $7.15 (LTM4622EV#PBF) |
| 65 | LTM4622 (dual output) | 2 | 3.1 | 20 | 2.5 | 2.5 | 600m | 5.5 | $7.15 (LTM4622EV#PBF) |
| 66 | LTM4677 (single output) | 1 | 4.5 | 16 | 36 | - | 500m | 1.8 | $39.60 (LTM4677EY#PBF) |
| 67 | LTM4677 (dual output) | 2 | 4.5 | 16 | 18 | 18 | 500m | 1.8 | $39.60 (LTM4677EY#PBF) |
| 68 | LTM4648 | 1 | 2.375 | 5.5 | 10 | - | 600m | 5 | $13.25 (LTM4648EY#PBF) |
| 69 | LTM4625 | 1 | 4 | 20 | 5 | - | 600m | 5.5 | $6.45 (LTM4625EY#PBF) |
| 70 | LTM4634 | 3 | 4.75 | 28 | 5 | 5 | 800m | 5.5 | $35.95 (LTM4634EY#PBF) |
| 71 | LTM4644 | 4 | 4 | 14 | 4 | 4 | 600m | 5.5 | $22.85 (LTM4644EY#PBF) |
| 72 | LTM4639 | 1 | 2.375 | 7 | 20 | - | 600m | 5.5 | $19.45 (LTM4639EY#PBF) |
| 73 | LTM4623 | 1 | 4 | 20 | 3 | - | 600m | 5.5 | $6.05 (LTM4623EV#PBF) |
| 74 | LTM8050 | 1 | 3.6 | 58 | 2 | - | 800m | 24 | $14.00 (LTM8050EY#PBF) |
| 75 | LTM4630 (single output) | 1 | 4.5 | 15 | 36 | - | 600m | 1.8 | $35.05 (LTM4630EV#PBF) |
| 76 | LTM4630 (dual output) | 2 | 4.5 | 15 | 18 | 18 | 600m | 1.8 | $35.05 (LTM4630EV#PBF) |
| 77 | LTM4624 | 1 | 4 | 14 | 4 | - | 600m | 5.5 | $5.95 (LTM4624EY#PBF) |
| 78 | LTM8028 | 1 | 6 | 36 | 5 | - | 800m | 1.8 | $14.20 (LTM8028EY#PBF) |
| 79 | LTM4649 | 1 | 4.5 | 16 | 10 | - | 600m | 3.3 | $13.05 (LTM4649EY#PBF) |
| 80 | LTM4637 | 1 | 4.5 | 20 | 20 | - | 600m | 5.5 | $22.10 (LTM4637EV#PBF) |
| 81 | LTM8001 | 6 | 6 | 36 | 5 | 1.1 | 1.2 | 24 | $17.40 (LTM8001EY#PBF) |
| 82 | LTM4641 | 1 | 4.5 | 38 | 10 | - | 600m | 6 | $25.95 (LTM4641EY#PBF) |
| 83 | LTM4620A (single output) | 1 | 4.5 | 16 | 26 | - | 600m | 5.3 | $31.28 (LTM4620AEV#PBF) |
| 84 | LTM4620A (dual output) | 2 | 4.5 | 16 | 13 | 13 | 600m | 5.3 | $31.28 (LTM4620AEV#PBF) |
| 85 | LTM4633 | 3 | 4.7 | 16 | 10 | 10 | 800m | 5.5 | $35.95 (LTM4633EY#PBF) |
| 86 | LTM8029 | 1 | 4.5 | 36 | 600m | - | 1.2 | 18 | $6.60 (LTM8029EY#PBF) |
| 87 | LTM4620 (single output) | 1 | 4.5 | 16 | 26 | - | 600m | 2.5 | $29.99 (LTM4620EV#PBF) |
| 88 | LTM4620 (dual output) | 2 | 4.5 | 16 | 13 | 13 | 600m | 2.5 | $29.99 (LTM4620EV#PBF) |
| 89 | LTM8026 | 1 | 6 | 36 | 5 | - | 1.2 | 24 | $12.58 (LTM8026EV#PBF) |
| 90 | LTM8052A | 1 | 6 | 36 | 5 | - | 1.2 | 24 | $13.17 (LTM8052AEV#PBF) |
| 91 | LTM8052 | 1 | 6 | 36 | 5 | - | 1.2 | 24 | $13.17 (LTM8052EV#PBF) |
| 92 | LTM4613 | 1 | 5 | 36 | 8 | - | 3.3 | 15 | $24.40 (LTM4613EV#PBF) |
| 93 | LTM4628 (dual output) | 2 | 4.5 | 26.5 | 8 | 8 | 600m | 5.5 | $19.90 (LTM4628EV#PBF) |
| 94 | LTM4627 | 1 | 4.5 | 20 | 15 | - | 600m | 5 | $17.99 (LTM4627EV#PBF) |
| 95 | LTM4618 | 1 | 4.5 | 26.5 | 6 | - | 800m | 5 | $11.30 (LTM4618EV#PBF) |
| 96 | LTM8033 | 1 | 3.6 | 36 | 3 | - | 800m | 24 | $11.95 (LTM8033EV#PBF) |
| 97 | LTM4611 | 1 | 1.5 | 5.5 | 15 | - | 800m | 5 | $19.45 (LTM4611EV#PBF) |
| 98 | LTM8031 | 1 | 3.6 | 36 | 1 | - | 800m | 10 | $9.95 (LTM8031EV#PBF) |
| 99 | LTM8027 | 1 | 4.5 | 60 | 4 | - | 2.5 | 24 | $16.50 (LTM8027EV#PBF) |
| 100 | LTM8025 | 1 | 3.6 | 36 | 3 | - | 800m | 24 | $8.95 (LTM8025EV#PBF) |
| 101 | LTM4619 | 2 | 4.5 | 26.5 | 4 | 4 | 800m | 5 | $16.75 (LTM4619EV#PBF) |
| 102 | LTM4615 | 3 | 2.375 | 5.5 | 4 | 4 | 800m | 5 | $17.20 (LTM4615EV#PBF) |
| 103 | LTM4612 | 1 | 5 | 36 | 5 | - | 3.3 | 15 | $19.89 (LTM4612EV#PBF) |
| 104 | LTM4608A | 1 | 2.7 | 5.5 | 8 | - | 600m | 5 | $11.30 (LTM4608AEV#PBF) |
| 105 | LTM4606 | 1 | 4.5 | 28 | 6 | - | 600m | 5 | $16.50 (LTM4606EV#PBF) |
| 106 | LTM4604A | 1 | 2.375 | 5.5 | 4 | - | 800m | 5 | $8.50 (LTM4604AEV#PBF) |
| 107 | LTM8021 | 1 | 3 | 36 | 500m | - | 800m | 5 | $5.85 (LTM8021EV#PBF) |
| 108 | LTM4616 | 2 | 2.7 | 5.5 | 8 | 8 | 600m | 5 | $19.45 (LTM4616EV#PBF) |
| 109 | LTM8032 | 1 | 3.6 | 36 | 2 | - | 800m | 10 | $10.95 (LTM8032EV#PBF) |
| 110 | LTM4614 | 2 | 2.375 | 5.5 | 4 | 4 | 800m | 5 | $15.50 (LTM4614EV#PBF) |
| 111 | LTM4601AHV | 1 | 4.5 | 28 | 12 | - | 600m | 5 | $20.40 (LTM4601AHVEV#PBF) |
| 112 | LTM8020 | 1 | 4 | 36 | 200m | - | 1.2 | 5 | $4.95 (LTM8020EV#PBF) |
| 113 | LTM4601A | 1 | 4.5 | 20 | 12 | - | 600m | 5 | $16.40 (LTM4601AEV-1#PBF) |
| 114 | LTM4603HV | 1 | 4.5 | 28 | 6 | - | 600m | 5 | $16.47 (LTM4603HVEV#PBF) |
| 115 | LTM8023 | 1 | 3.6 | 36 | 2 | - | 800m | 10 | $7.95 (LTM8023EV#PBF) |
| 116 | LTM8022 | 1 | 3.6 | 36 | 1 | - | 800m | 10 | $6.95 (LTM8022EV#PBF) |
| 117 | LTM4603 | 1 | 4.5 | 20 | 6 | - | 600m | 5 | $12.95 (LTM4603EV-1#PBF) |
| 118 | LTM4602HV | 1 | 4.5 | 28 | 6 | - | 600m | 5 | $14.58 (LTM4602HVEV#PBF) |
| 119 | LTM4602 | 1 | 4.5 | 20 | 6 | - | 600m | 5 | $11.95 (LTM4602EV#PBF) |
| 120 | LTM4601HV | 1 | 4.5 | 28 | 12 | - | 600m | 5 | $20.15 (LTM4601HVEV#PBF) |
| 121 | LTM4601 | 1 | 4.5 | 20 | 12 | - | 600m | 5 | $15.95 (LTM4601EV-1#PBF) |
| 122 | LTM4600HV | 1 | 4.5 | 28 | 10 | - | 600m | 5 | $18.00 (LTM4600HVEV#PBF) |
| 123 | LTM4600 | 1 | 4.5 | 20 | 10 | - | 600m | 5 | $14.70 (LTM4600EV#PBF) |
