单电源监视器
Analog Devices 的单电源监控电路提供了许多可帮助简化设计的优势，例如：高准确度、可调门限和容差、和一个在低电源电压条件下有保证的 RESET 信号。大多数 ADI 监控器都具有围绕标称门限电压的 exhibit ±1.5% 门限准确度，从而最大限度减小了所需的系统电压裕度和系统故障概率。具有可调或引脚可选门限和容差的电压监控器为用户提供了最大的灵活性，允许于多款设计使用单一器件。另外，ADI 的监控器还可在业界领先的 0.5 V 低电压下保证提供一个有效的复位信号，以帮助保持系统完整性。
产品选型表
最新优势资源
单电源监视器
| SortOrder | Part# | Reset Voltage | Threshold Accuracy (typ) (%) | Isupply (typ) (A) | Features | Watchdog Timer | Vs+ (max) (V) | Price (1000+) ($ US) |
|---|---|---|---|---|---|---|---|---|
| 1 | LTC2965 | Adj | 1.4 | 7µ | Polarity Selection, Selectable Hysteresis | No | 100 | $1.98 (LTC2965CDD#PBF) |
| 2 | ADM8642 | Adj | 1.3 | 200µ | Supervisor | No | 5.5 | $0.25 (ADM8642T100ACBZ-R7) |
| 3 | ADM8641 | Adj | 1.3 | 92n | Supervisor | No | 5.5 | $0.25 (ADM8641T263ACBZ-R7) |
| 4 | ADM8615 | Adj | 1.3 | 20µ | Supervisor, Watchdog Timer | Yes | 5.5 | $0.59 (ADM8615Y100ACBZ-R7) |
| 5 | ADM8614 | Adj | 1.3 | 92n | Supervisor, Watchdog Timer | Yes | 3.6 | $0.59 (ADM8614Y263ACBZ-R7) |
| 6 | ADM8613 | Adj | 1.3 | 92n | Supervisor, Watchdog Timer | Yes | 5.5 | $0.59 (ADM8613Y232ACBZ-R7) |
| 7 | ADM8612 | Adj | 1.3 | 92n | Supervisor | No | 5.5 | $0.42 (ADM8612N110ACBZ-R7) |
| 8 | ADM8611 | Adj | 1.3 | 92n | Supervisor | No | 5.5 | $0.39 (ADM8611N263ACBZ-R7) |
| 9 | ADM8324 | Adj | 1.5 | 92n | Supervisor, Watchdog Timer | Yes | 5.5 | $0.79 (ADM8324WAH29ARJZR7) |
| 10 | ADM8323 | Adj | 1.5 | 10µ | Supervisor, Watchdog Timer | Yes | 5.5 | $0.79 (ADM8323WCC29ARJZR7) |
| 11 | ADM8322 | Adj | 1.5 | 10µ | Supervisor, Watchdog Timer | Yes | 5.5 | $0.69 (ADM8322WB26ARJZRL7) |
| 12 | ADM8321 | Adj | 1.5 | 10µ | Supervisor, Watchdog Timer | Yes | 5.5 | $0.69 (ADM8321WAX30ARJZR7) |
| 13 | ADM8320 | Adj | 1.5 | 10µ | Supervisor, Watchdog Timer | Yes | 5.5 | $0.69 (ADM8320WBX3NARJZR7) |
| 14 | ADM8319 | Adj | 1.5 | 10µ | Supervisor, Watchdog Timer | Yes | 5.5 | $0.69 (ADM8319WB31ARJZR7) |
| 15 | ADM8318 | Adj | 1.5 | 10µ | Supervisor, Watchdog Timer | Yes | 5.5 | $0.69 (ADM8318WCY46ARJZR7) |
| 16 | ADM8316 | Adj | 1.5 | 10µ | Supervisor, Watchdog Timer | Yes | 5.5 | $0.69 (ADM8316WAY27ARJZR7) |
| 17 | ADM6346 | Adj | 2.5 | 500n | Supervisor | No | 5.5 | $0.95 (ADM6346-46ARTZ-R7) |
| 18 | ADM6328 | Adj | 2.5 | 115µ | Supervisor | No | 5.5 | $0.95 (ADM6328-22ARTZ-R7) |
| 19 | ADM6326 | Adj | 2.5 | 500n | Supervisor | No | 5.5 | $0.95 (ADM6326-22ARTZ-R7) |
| 20 | LTC2935 | 2.25V, 2.4V, 2.55V, 2.7V, 2.85V, 3.15V, 3.3V, 3V | 1.5 | 500n | Supervisor | No | 6 | $1.22 (LTC2935CDC-1#TRPBF) |
| 21 | LTC2934 | Adj | 1.5 | 500n | Supervisor | No | 6 | $1.15 (LTC2934CDC-1#TRPBF) |
| 22 | LTC2918 | Adj | 1.5 | 30µ | Supervisor, Watchdog Timer | Yes | 6.2 | $1.30 (LTC2918CDDB-A1#TRPBF) |
| 23 | LTC2917 | Adj | 1.5 | 30µ | Supervisor, Watchdog Timer | Yes | 6.2 | $1.30 (LTC2917CDDB-A1#TRPBF) |
| 24 | LTC2953-2 | Adj, -Adj | 1.5 | 14µ | Pushbutton, Supervisor | No | 27 | $2.30 (LTC2953CDD-2#PBF) |
| 25 | LTC2953-1 | Adj, -Adj | 1.5 | 14µ | Pushbutton, Supervisor | No | 27 | $2.30 (LTC2953CDD-1#PBF) |
| 26 | LTC2916 | 1.2V, 1.5V, 1.8V, 12V, 1V, 2.5V, 3.3V, 5V, Adj | 1.5 | 30µ | Supervisor | No | 6.2 | $1.05 (LTC2916CDDB-1#TRPBF) |
| 27 | LTC2915 | 1.2V, 1.5V, 1.8V, 12V, 1V, 2.5V, 3.3V, 5V, Adj | 1.5 | 30µ | Supervisor | No | 6.2 | $1.05 (LTC2915CDDB-1#TRPBF) |
| 28 | LTC2952 | Adj, -Adj | 1.5 | 25µ | Diode-OR Controller, Pushbutton, Supervisor, Watchdog Timer | Yes | 28 | $2.95 (LTC2952CF#PBF) |
| 29 | LTC2912 | Adj | 1.5 | 40µ | Supervisor | No | 6.6 | $1.45 (LTC2912CDDB-1#TRPBF) |
| 30 | ADM8617 | Adj | 2.5 | 92n | Supervisor, Watchdog Timer | Yes | 5.5 | $1.05 (ADM8617RCYAKSZ-RL7) |
| 31 | ADM8616 | Adj | 2.5 | 20µ | Supervisor, Watchdog Timer | Yes | 5.5 | $1.05 (ADM8616LCYAKSZ-RL7) |
| 32 | ADM6823 | Adj | 2.5 | 1.95m | Supervisor, Watchdog Timer | Yes | 5.5 | $0.89 (ADM6823RYRJZ-RL7) |
| 33 | ADM6384 | Adj | 2.5 | 115µ | Supervisor | No | 5.5 | $1.11 (ADM6384YKS17D3Z-R7) |
| 34 | ADM825 | Adj | 2.5 | 10µ | Supervisor, Watchdog Timer | No | 5.5 | $0.53 (ADM825RYRJZ-R7) |
| 35 | ADM824 | Adj | 2.5 | 24µ | Supervisor, Watchdog Timer | Yes | 5.5 | $0.53 (ADM824LYRJZ-REEL7) |
| 36 | ADM823 | Adj | 2.5 | 24µ | Supervisor, Watchdog Timer | Yes | 5.5 | $0.53 (ADM823LYKSZ-R7) |
| 37 | ADM6322 | Adj | 2.5 | 500n | Supervisor | No | 5.5 | $0.52 (ADM6322C29ARJZ-RL7) |
| 38 | ADM6321 | Adj | 2.5 | 20µ | Supervisor, Watchdog Timer | Yes | 5.5 | $0.62 (ADM6321AY30ARJZ-R7) |
| 39 | ADM6320 | Adj | 2.5 | 20µ | Supervisor, Watchdog Timer | Yes | 5.5 | $0.53 (ADM6320BX33ARJZ-R7) |
| 40 | ADM6319 | Adj | 2.5 | 20µ | Supervisor | No | 5.5 | $0.61 (ADM6319C29ARJZ-RL7) |
| 41 | ADM6318 | Adj | 2.5 | 20µ | Supervisor, Watchdog Timer | Yes | 5.5 | $0.52 (ADM6318BX49ARJZ-R7) |
| 42 | ADM6316 | Adj | 2.5 | 20µ | Supervisor, Watchdog Timer | Yes | 5.5 | $0.53 (ADM6316AY27ARJZ-R7) |
| 43 | ADM803 | Adj | 1.5 | 100µ | Supervisor | No | 5.5 | $0.27 (ADM803LAKSZ-REEL) |
| 44 | ADM6713 | Adj | 1.5 | 10µ | Supervisor | No | 5.5 | $0.29 (ADM6713LAKSZ-REEL7) |
| 45 | ADM6711 | Adj | 1.5 | 35µ | Supervisor | No | 5.5 | $0.29 (ADM6711LAKSZ-REEL7) |
| 46 | ADM812 | Adj | 1.5 | 24µ | Supervisor | No | 5.5 | $0.46 (ADM812LARTZ-REEL7) |
| 47 | ADM1816 | Adj | 1.5 | 16µ | Supervisor | No | 5.5 | $0.50 (ADM1816-10ARTZ-RL7) |
| 48 | ADM1813 | 4.35v, 4.62V | 1.5 | 16µ | Supervisor | No | 5.5 | $0.39 (ADM1813-5ARTZ-RL7) |
| 49 | ADM1815 | Adj | 1.5 | 16µ | Supervisor | No | 5.5 | $0.43 (ADM1815-5ARTZ-RL7) |
| 50 | ADM811 | Adj | 1.5 | 15µ | Supervisor | No | 5.5 | $0.46 (ADM811LARTZ-REEL7) |
| 51 | ADM6315 | Adj | 2.5 | 20µ | Supervisor | No | 5.5 | $0.82 (ADM6315-26D1ARTZR7) |
| 52 | ADM1818 | Adj | 1.5 | 62µ | Pushbutton, Supervisor | No | 5.5 | $0.45 (ADM1818-10ARTZ-RL7) |
| 53 | ADM1812 | 4.35v, 4.62V | 1.5 | 16µ | Supervisor | No | 5.5 | $0.46 (ADM1812-10ARTZ-RL7) |
| 54 | ADM1811 | 4.35v, 4.62V | 1.5 | 16µ | Supervisor | No | 5.5 | $0.46 (ADM1811-10ARTZ-RL7) |
| 55 | ADM1810 | 4.35v, 4.62V | 1.5 | 16µ | Supervisor | No | 5.5 | $0.46 (ADM1810-10ARTZ-RL7) |
| 56 | ADM9690 | 4.31V | 1.5 | 100µ | Supervisor, Watchdog Timer | Yes | 5.5 | $1.67 (ADM9690ARNZ) |
| 57 | ADM1232 | 4.37V, 4.62V | 2.5 | 50µ | Supervisor, Watchdog Timer | Yes | 5.5 | $1.05 (ADM1232ANZ) |
| 58 | ADM8699 | 4.65V | 2.5 | 55µ | Supervisor, Watchdog Timer | Yes | 5.5 | $2.35 (ADM8699ARNZ) |
| 59 | ADM8697 | Adj | 2.5 | 100µ | Supervisor, Watchdog Timer | Yes | 5.5 | $3.18 (ADM8697ARWZ) |
| 60 | ADM8696 | 1.3V | 2.5 | 200µ | Supervisor, Watchdog Timer | Yes | 5.5 | $3.18 (ADM8696ARWZ) |
| 61 | ADM8695 | 4.65V | 2.5 | 200µ | Supervisor, Watchdog Timer | Yes | 5.5 | $2.56 (ADM8695ARWZ) |
| 62 | ADM8691 | 4.65V | 2.5 | 200µ | Supervisor, Watchdog Timer | Yes | 5.5 | $3.53 (ADM8691ARWZ) |
| 63 | ADM8690 | 4.65V | 2.5 | 200µ | Supervisor, Watchdog Timer | Yes | 5.5 | $2.95 (ADM8690ARNZ) |
| 64 | ADM810 | Adj | 1.5 | 15µ | Supervisor | No | 5.5 | $0.61 (ADM810JARTZ-REEL7) |
| 65 | ADM809 | Adj | 1.5 | 60µ | Supervisor | No | 5.5 | $0.63 (ADM809-5LARTZ-RL7) |
| 66 | ADM805 | 4.4V, 4.65V | - | 60µ | Supervisor, Watchdog Timer | Yes | 5.5 | $2.45 (ADM805LANZ) |
| 67 | ADM802 | 4.4V, 4.65V | - | 60µ | Supervisor, Watchdog Timer | Yes | 5.5 | $2.23 (ADM802LARNZ) |
| 68 | ADM800 | 4.4V, 4.65V | - | 100µ | Supervisor, Watchdog Timer | Yes | 5.5 | $2.33 (ADM800MARNZ) |
| 69 | ADM693A | 4.4V | - | 1.95m | Supervisor, Watchdog Timer | Yes | 5.5 | $1.85 (ADM693AANZ) |
| 70 | ADM692A | 4.4V | - | 1.95m | Supervisor, Watchdog Timer | Yes | 5.5 | $1.68 (ADM692AANZ) |
| 71 | ADM691A | 4.65V | - | 1.95m | Supervisor, Watchdog Timer | Yes | 5.5 | $1.73 (ADM691AARUZ) |
| 72 | ADM690A | 4.65V | - | 1.95m | Supervisor, Watchdog Timer | Yes | 5.5 | $1.73 (ADM690AARMZ) |
| 73 | ADM709 | Adj | - | 100µ | Supervisor | No | 5.5 | $0.71 (ADM709LANZ) |
| 74 | ADM708 | 4.4V | - | 200µ | Supervisor | No | 5.5 | $0.85 (ADM708ANZ) |
| 75 | ADM707 | 4.65V | - | 250µ | Supervisor | No | 5.5 | $0.97 (ADM707ANZ) |
| 76 | ADM706 | 4.4V | - | 250µ | Supervisor, Watchdog Timer | Yes | 5.5 | $1.70 (ADM706ANZ) |
| 77 | ADM705 | 4.65V | - | 250µ | Supervisor, Watchdog Timer | Yes | 5.5 | $1.02 (ADM705ANZ) |
| 78 | LTC693 | 5V | 2 | 600µ | Supervisor, Watchdog Timer | Yes | 6 | $3.70 (LTC693CN#PBF) |
| 79 | LTC692 | 5V | 2 | 600µ | Supervisor, Watchdog Timer | Yes | 6 | $3.40 (LTC692CN8#PBF) |
| 80 | ADM699 | 4.65V | - | 250µ | Supervisor, Watchdog Timer | Yes | 5.5 | $1.93 (ADM699ANZ) |
| 81 | ADM698 | 4.65V | - | 1.95m | Supervisor | No | 5.5 | $1.58 (ADM698ANZ) |
| 82 | ADM697 | Adj | - | 1.95m | Supervisor, Watchdog Timer | Yes | 5.5 | $3.02 (ADM697ANZ) |
| 83 | ADM696 | Adj | - | 1.95m | Supervisor, Watchdog Timer | Yes | 5.5 | $3.31 (ADM696ARZ) |
| 84 | ADM695 | Adj | 1.7 | 1.95m | Supervisor, Watchdog Timer | Yes | 5.5 | $3.14 (ADM695ANZ) |
| 85 | ADM694 | 4.65V | 1.7 | 1.95m | Supervisor, Watchdog Timer | Yes | 5.5 | $2.91 (ADM694ANZ) |
| 86 | ADM693 | 4.4V | 1.8 | 100µ | Supervisor, Watchdog Timer | Yes | 5.5 | $3.14 (ADM693ANZ) |
| 87 | ADM692 | 4.4V | 1.8 | 100µ | Supervisor, Watchdog Timer | Yes | 5.5 | $2.78 (ADM692ANZ) |
| 88 | ADM691 | 4.65V | 1.7 | 100µ | Supervisor, Watchdog Timer | Yes | 5.5 | $3.14 (ADM691ANZ) |
| 89 | ADM690 | 4.65V | 1.7 | 100µ | Supervisor, Watchdog Timer | Yes | 5.5 | $3.06 (ADM690ANZ) |
| 90 | LTC694-3.3 | 2.90V | 3 | 600µ | Supervisor, Watchdog Timer | Yes | 6 | $3.65 (LTC694CN8-3.3#PBF) |
| 91 | LTC695-3.3 | 2.90V | 3 | 600µ | Supervisor, Watchdog Timer | Yes | 6 | $4.00 (LTC695CN-3.3#PBF) |
| 92 | LTC699 | 5V | 2 | 600µ | Supervisor, Watchdog Timer | Yes | 6 | $2.45 (LTC699CN8#PBF) |
| 93 | LTC1232 | 5V | 2.5 | 500µ | Supervisor, Watchdog Timer | Yes | 5.5 | $1.75 (LTC1232CN8#PBF) |
| 94 | LTC695 | 5V | 2 | 600µ | Supervisor, Watchdog Timer | Yes | 6 | $3.70 (LTC695CN#PBF) |
| 95 | LTC694 | 5V | 2 | 600µ | Supervisor, Watchdog Timer | Yes | 6 | $3.40 (LTC694CN8#PBF) |
| 96 | LTC691 | 5V | 2 | 600µ | Supervisor, Watchdog Timer | Yes | 6 | $3.70 (LTC691CN#PBF) |
| 97 | LTC690 | 5V | 2 | 600µ | Supervisor, Watchdog Timer | Yes | 6 | $3.40 (LTC690CN8#PBF) |
