CM4xx混合信号控制处理器

ADI公司的ADSP-CM4xx混合信号控制处理器采用ARM®-Cortex™ M4处理器内核,集成高精度ADC、数字加速器和滤波器、SRAM和闪存以及丰富的外设。此处理器适合要求高性能实时控制和模拟转换的各类嵌入式应用。

CM4xx Mixed Signal Control Processors

  按住Shift键进行二次排序
SortOrderPart#Clock Max SpeedsENOB
(typ)
(bits)
ChannelsMemory SRAM on chipMemory Flash on chipUSB InterfaceSerial Comms PortsEthernet Protocol SupportedMemory Ext TypesGPIO pinsSpecial FeaturesADC Simultaneous SamplingUS Price 1000 to 4999
($ US)
1ADSP-CM418F 240 MHz 12 31 128 kB, 160 kB 256 kB, 512 kB- 1 I2C, 2 CAN, 2 SPI, 3 UARTS No 16 bit EMIF 73 CORDIC, Enhanced PWM, FFT Arching Detection, FOCP, HAE, Math Function Block, SINC filters 4, SMC 6 Way-
2ADSP-CM417F 240 MHz 14 24 160 kB 1 MB, 512 kB- 1 I2C, 2 CAN, 2 SPI, 3 UARTS No 16 bit EMIF 73 CORDIC, Enhanced PWM, FFT Arching Detection, FOCP, HAE, Math Function Block, SINC filters 4, SMC 3 Way-
3ADSP-CM416F 240 MHz 12 24 128 kB, 160 kB 256 kB, 512 kB- 1 I2C, 2 CAN, 2 SPI, 3 UARTS No 16 bit EMIF 73 CORDIC, Enhanced PWM, FFT Arching Detection, FOCP, HAE, Math Function Block, SINC filters 4, SMC 3 Way-
4ADSP-CM413F 240 MHz 14 24 128 kB, 160 kB 256 kB, 512 kB- 1 I2C, 2 CAN, 2 SPI, 3 UARTS No 16 bit EMIF 73 Enhanced PWM, FOCP, Math Function Block, SINC filters 4, SMC 3 Way-
5ADSP-CM412F 180 MHz, 240 MHz 12 24 128 kB 256 kB-- No- 73- 3 Way-
6ADSP-CM411F 180 MHz, 240 MHz 12 24- 256 kB No 1 I2C, 2 CAN, 2 SPI, 5 UARTs No 16 bit EMIF 73 Enhanced PWM, FOCP, Math Function Block, SINC filters 4, SMC 3 Way-
7ADSP-CM419F 240 MHz 14 31 160 kB 512 kB- 1 I2C, 2 CAN, 2 SPI, 3 UARTS No 16 bit EMIF 73 CORDIC, Enhanced PWM, FFT Arching Detection, FOCP, HAE, Math Function Block, SINC filters 4, SMC 6 Way-
8ADSP-CM409F 240 MHz 14 24 384 kB 2 MB Yes 1 I2C, 2 CAN, 3 UARTS Yes 16 bit EMIF 91 HAE, PWM Units, QEP 2, SINC filters 4- $14.05
9ADSP-CM403F-F 100 MHz 14 24- 256 kB- 1 I2C, 2 CAN, 3 UARTS- 16 bit EMIF 40 HAE, PWM Units, QEP 2, SINC filters 4- $9.39
10ADSP-CM403F-E 150 MHz 14 24--- 1 I2C, 2 CAN, 3 UARTS- 16 bit EMIF 40 HAE, PWM Units, QEP 2, SINC filters 4- $9.70
11ADSP-CM403F-C 240 MHz 14 24- 2 MB- 1 I2C, 2 CAN, 3 UARTS- 16 bit EMIF 40 HAE, PWM Units, QEP 2, SINC filters 4- $11.89
12ADSP-CM402F-F 100 MHz 12 24- 256 kB- 1 I2C, 2 CAN, 3 UARTS- 16 bit EMIF 40 HAE, PWM Units, QEP 2, SINC filters 4- $8.14
13ADSP-CM402F-E 150 MHz 12 24--- 1 I2C, 2 CAN, 3 UARTS- 16 bit EMIF 40 HAE, PWM Units, QEP 2, SINC filters 4- $8.76
14ADSP-CM408F-B 240 MHz 14 16- 2 MB Yes 1 I2C, 2 CAN, 3 UARTS- 16 bit EMIF 91 HAE, PWM Units, QEP 2, SINC filters 4- $13.15
15ADSP-CM408F-A 240 MHz 14 16- 2 MB Yes 1 I2C, 2 CAN, 3 UARTS Yes 16 bit EMIF 91 HAE, PWM Units, QEP 2, SINC filters 4- $13.77
16ADSP-CM407F-D 150 MHz 12 16- 1 MB- 1 I2C, 2 CAN, 3 UARTS- 16 bit EMIF 91 HAE, PWM Units, QEP 2, SINC filters 4- $8.14
17ADSP-CM407F-B 240 MHz 12 16- 2 MB Yes 1 I2C, 2 CAN, 3 UARTS- 16 bit EMIF 91 HAE, PWM Units, QEP 2, SINC filters 4- $11.89
18ADSP-CM407F-A 240 MHz 12 16- 2 MB Yes 1 I2C, 2 CAN, 3 UARTS Yes 16 bit EMIF 91 HAE, PWM Units, QEP 2, SINC filters 4- $12.52
