基准电压源

ADI公司提供业界种类最齐全的高性能基准电压源。我们既有适合高端工业应用的高精度、低噪声产品,也有针对手持式电池供电应用的通用低功耗产品。ADI正是设计工程师寻求高性价比、性能可靠、值得信赖的完美基准电压源的最终供应商。
产品选型表

Voltage References

  按住Shift键进行二次排序
SortOrderPart#Vref TypeVout Rating
(V)
Iout Sourcing (max)
(A)
Iout Sinking (max)
(A)
Initial Accuracy % (max)
(%)
Vout Tempco (max)
(ppm/°C)
Vsupply (min)
(V)
Vsupply (max)
(V)
Vnoise (typ)
(V p-p)
Initial Accuracy mV (max)
(V)
US Price 1000 to 4999
($ US)
1AD780S-----------
2ADR225-KGD-CHIPSReference Circuit Available----- 10 3.3 16 25µ 10m $79.00
3ADR225Reference Circuit Available------ 3.3 16 25µ 10m $73.00
4ADR3512 Series (Low Dropout) 1.2 10m -3m 0.1 8 2.3 5.5 1.2m $3.25
5ADR4550Reference Circuit Available Series (Low Dropout) 5 10m 10m 0.02 2 5.1 15 2.8µ 1m $2.45
6ADR4540 Series (Low Dropout) 4.096 10m 10m 0.02 2 4.2 15 2.7µ 820µ $2.45
7ADR4533 Series (Low Dropout) 3.3 10m 10m 0.02 2 3.4 15 2.1µ 660µ $2.45
8ADR4530 Series (Low Dropout) 3 10m 10m 0.02 2 3.1 15 1.6µ 600µ $2.45
9ADR4525Reference Circuit Available Series (Low Dropout) 2.5 10m 10m 0.02 2 3 15 1.25µ 500µ $2.45
10ADR4520 Series (Low Dropout) 2.048 10m 8m 0.02 2 3 15 410µ $2.45
11ADR3550 Series 5 10m 3m 0.1 5 5.2 5.5 35µ 5m $1.14
12ADR3540 Series 4.096 10m 3m 0.1 5 4.3 5.5 29µ 4.096m $1.14
13ADR3533 Series 3.3 10m 3m 0.1 5 3.5 5.5 25µ 3.3m $1.14
14ADR3530 Series 3 10m 3m 0.1 5 3.2 5.5 22µ 3m $1.14
15ADR3525 Series 2.5 10m 3m 0.1 5 2.7 5.5 18µ 2.5m $1.14
16ADR3433Reference Circuit Available Series (Low Dropout) 3.3 10m 3m 0.1 8 3.5 5.5 25µ 3.3m $0.93
17ADR3420 Series (Low Dropout) 2.048 10m 3m 0.1 8 2.3 5.5 15µ 2.048m $0.93
18ADR3412Reference Circuit Available Series (Low Dropout) 1.2 10m 3m 0.1 8 2.3 5.5 1.2m $0.93
19ADR3450 Series 5 10m 3m 0.1 8 5.2 5.5 35µ 5m $0.93
20ADR3440Reference Circuit Available Series 4.096 10m 3m 0.1 8 4.3 5.5 29µ 4.096m $0.93
21ADR3430 Series 3 10m 3m 0.1 8 3.2 5.5 22µ 3m $0.93
22ADR3425 Series 2.5 10m 3m 0.1 8 2.7 5.5 18µ 2.5m $0.93
23ADR827 Series 1.25 5m 3m 0.2 15 2.7 15 2.5m $1.45
24ADR1581Reference Circuit Available Shunt 1.25 10m 1m 0.12 100-- 4.5µ 1.5m $0.61
25ADR5045 Shunt 5 15m- 0.1 75-- 18.67µ 5m $0.28
26ADR5044 Shunt 4.096 15m- 0.1 75-- 15.27µ 4.096m $0.28
27ADR5043 Shunt 3 15m- 0.1 75-- 12.16µ 3m $0.28
28ADR5041 Shunt 2.5 15m- 0.1 75-- 9.05µ 2.5m $0.28
29ADR5040 Shunt 2.048 15m- 0.1 75-- 7.92µ 2.048m $0.28
30ADR130-1.0 Series (Multi/Select Out) 1--- 25 2 18 3.5m $1.27
31ADR130-0.5 Series (Multi/Select Out) 0.5--- 25 2 18 3.5m $1.27
32ADR127 Series 1.25 5m 0m 0.12 9 2.7 18 1.5m $1.59
33ADR1500 Shunt 1.29 10m 1m 0.2 170-- 2.6m $1.03
34ADR445Reference Circuit Available Series (Low Dropout) 5 10m 5m 0.04 3 5.5 18 2.25µ 2m $2.78
35ADR444Reference Circuit Available Series (Low Dropout) 4.096 10m 5m 0.04 3 4.6 18 1.8µ 1.6m $2.78
36ADR443 Series (Low Dropout) 3 10m 5m 0.04 3 3.5 18 1.4µ 1.2m $2.78
37ADR441Reference Circuit Available Series (Low Dropout) 2.5 10m 5m 0.04 3 3 18 1.2µ 1m $2.78
38ADR440 Series (Low Dropout) 2.048 10m 5m 0.05 3 3 18 1m $2.78
39ADR366 Series (Low Dropout) 3.3 5m- 0.125 9 3.6 15 9.3µ 4m $0.78
40ADR365 Series (Low Dropout) 5 5m- 0.08 9 5.3 15 12.8µ 4m $0.82
41ADR364 Series (Low Dropout) 4.096 5m- 0.1 9 4.4 15 11µ 4m $0.82
42ADR363 Series (Low Dropout) 3 5m- 0.1 9 3.3 15 8.7µ 3m $0.82
43ADR361 Series (Low Dropout) 2.5 5m- 0.12 9 2.8 15 8.25µ 3m $0.82
44ADR360 Series (Low Dropout) 2.048 5m- 0.15 9 2.35 15 6.8µ 3m $0.84
45ADR435Reference Circuit Available Series 5 30m 20m 0.04 3 7 18 2m $2.96
46ADR434Reference Circuit Available Series 4.096 30m 20m 0.04 3 6.1 18 6.25µ 1.5m $3.85
47ADR433 Series 3 30m 20m 0.05 3 5 18 3.75µ 1.5m $2.96
48ADR431Reference Circuit Available Series 2.5 30m 20m 0.04 3 4.5 18 3.5µ 1m $2.96
49ADR430 Series 2.048 30m 20m 0.05 3 4.1 18 3.5µ 1m $2.96
50ADR550 Shunt 5-- 0.2 40-- 38µ 10m $0.49
51ADR530 Shunt 3-- 0.2 40-- 22µ 6m $0.64
52ADR525 Shunt 2.5-- 0.2 40-- 18µ 5m $0.49
53ADR06 Series 3 10m- 0.1 3 5 36 10µ 3m $1.05
54ADR512 Shunt 1.2 10m- 0.3 60-- 3.5m $0.67
55ADR510 Shunt 1-- 0.35 70-- 3.5m $0.61
56ADR03Reference Circuit Available Series 2.5 10m- 0.1 3 4.5 36 2.5m $1.05
57ADR395Reference Circuit Available Series (Low Dropout) 5 5m- 0.1 9 5.3 15 5m $0.88
58ADR392 Series (Low Dropout) 4.096 5m- 0.12 9 4.3 15 5m $0.88
59ADR280Reference Circuit Available Series 1.2 100µ- 0.4 40 2.4 5.5 2.2µ 5m $0.82
60ADR02Reference Circuit Available Series 5 10m- 0.06 3 7 36 10µ 3m $1.05
61ADR01Reference Circuit Available Series 10 10m- 0.05 3 12 36 20µ 5m $1.05
62ADR425 Series 5 10m- 0.04 3 7 18 3.4µ 2m $2.88
63ADR423 Series 3 10m- 0.04 3 5 18 1.5m $2.88
64ADR421Reference Circuit Available Series 2.5 10m- 0.04 3 4.5 18 1.75µ 1m $2.88
65ADR420Reference Circuit Available Series 2.048 10m- 0.05 3 4 18 1.75µ 1m $2.88
66ADR381Reference Circuit Available Series (Low Dropout) 2.5 5m- 0.24 25 2.8 18 6m $0.78
67ADR380 Series (Low Dropout) 2.048 5m- 0.24 25 2.4 18 5m $0.78
68ADR391Reference Circuit Available Series (Low Dropout) 2.5 5m- 0.16 9 2.8 15 4m $0.88
69ADR293 Series 5 5m- 0.06 25 6 15 15µ 3m $2.05
70ADR292 Series 4.096 5m- 0.07 8 4.5 18 12µ 4.1m $2.09
71ADR291Reference Circuit Available Series (Low Dropout) 2.5 5m- 0.08 8 3 15 2.5m $2.37
72AD1585 Series (Low Dropout) 5 5m 0m 0.1 50 5.2 12 140µ 50m $0.67
73AD1584 Series (Low Dropout) 4.096 5m 0m 0.1 50 4.3 12 110µ 40m $0.67
74AD1583 Series (Low Dropout) 3 5m 0m 0.1 50 3.2 12 85µ 30m $0.67
75AD1582 Series (Low Dropout) 2.5 5m 0m 0.08 50 2.7 12 70µ 20m $0.67
76REF198 Series (Low Dropout) 4.096 30m- 0.049 5 5 18 40µ 2m $1.44
77REF191 Series (Low Dropout) 2.048 30m- 0.1 5 3.3 18 20µ 2m $1.44
78AD1580 Shunt 1.2-- 0.1 50-- 1m $0.62
79REF196 Series (Low Dropout) 3.3 30m- 0.0625 25 3.5 18 33µ 2m $1.44
80REF194Reference Circuit Available Series (Low Dropout) 4.5 30m- 0.044 5 5 18 45µ 2m $1.44
81REF193 Series (Low Dropout) 3 30m- 0.066 25 3.3 18 30µ 2m $1.44
82REF192Reference Circuit Available Series (Low Dropout) 2.5 30m- 0.08 5 3.3 18 25µ 2m $1.44
83REF195 Series (Low Dropout) 5 30m- 0.04 5 5.1 18 50µ 2m $1.44
84AD780Reference Circuit Available Series/Shunt 3 10m 0m 0.03 7 4 36 1m $4.51
85AD680 Series 2.5 5m 0.4 20 4.5 36 10m $1.84
86AD688 Series (Multi/Select Out) 10 10m 0m 0.02 1.5 10 38 2m $13.40
87REF03 Series 2.5 10m 300µ 0.6 50 4.5 36 15m $1.25
88REF43 Series 2.5 20m 1.2m 0.1 25 4.5 40 2.5m $3.84
89AD587 Series 10 10m 0m 0.05 5 13.5 36 5m $3.01
90AD586 Series 5 10m 0m 0.04 2 10.8 36 2m $3.01
91AD588 Series (Multi/Select Out) 10 10m 0m- 1.5 10.8 36 1m $17.92
92AD589 Shunt 1.2 10m 10m 1.2 10-- 15m $1.39
93AD584---------- $4.19
94AD581 Series 10 5m 0.05 5 12 40 40µ 5m $9.28
95REF02 Series 5 10m 300µ 0.3 8.5 7 36 15µ 15m $1.26
96REF01 Series 10 10m 300µ 0.3 8.5 12 36 30µ 30m $1.25
97AD580 Series 2.5 10m- 0.4 85 4.5 30 10m $4.62
